DC12V Or 24V Vehicle Refrigeration Unit Small Truck Refrigeration Unit Rooftop

Detail Information

Product Description

Detail Information

Model NO.:

SF-200

Sealing Technology:

Patented O Sealing Technology

Design Base Environment:

45 Degree C

Durability Range:

The Highest Level

Maintenance:

Lower The Cost Of Maintance

Transport Package:

Carton Filled With Paper Honeycomb

Trademark:

SNOWFALL

Origin:

Guangzhou, China

HS Code:

8418692090

Supply Ability:

300 Sets Per Month

Service:

OEM

Installation:

Front, Roof, Under Mounting Type

Electric:

Optional Electric Standby System

Colour:

White

Fan Material:

Aluminium Alloy

Condensor Design:

Latest Exclusively For Refrigeration Unit

Customization:

Available | Customized Request

Highlight:

24V Vehicle Refrigeration Unit

DC12V Small Truck Refrigeration Unit

Rooftop Small Truck Refrigeration Unit

Product Description

DC12V Or 24V Vehicle Refrigeration Unit Small Truck Refrigeration Unit Rooftop

Product Specifications

Model NO.	SF-200
Sealing Technology	Patented O Sealing Technology
Design Base Environment	45 Degree C
Durability Range	The Highest Level
Maintenance	Lower The Cost of Maintenance
Transport Package	Carton Filled with Paper Honeycomb
Trademark	SNOWFALL
Origin	Guangzhou, China
HS Code	8418692090
Supply Ability	300 Sets Per Month
Service	OEM
Installation	Front, Roof, Under Mounting Type
Electric	Optional Electric Standby System
Colour	White
Fan Material	Aluminium Alloy
Condenser Design	Latest Exclusively for Refrigeration Unit
Customization	Available

Product Overview

The SF-200 is designed for micro and light truck applications, featuring engine-driven refrigeration technology. Ideal for transporting refrigerated food, dairy products, vegetables, and fruits, this unit offers reliable temperature control for vehicles with 7-14m³ capacity.

Key Features

Optional DC 12V or 24V power configuration
Lightweight and compact design with front-mounted condenser
Precisely matched cooling capacity for 7-14m³ spaces
Low maintenance, low noise operation with energy efficiency
Patented O sealing technology for superior durability
Available with optional electric standby system
Environmentally friendly R134a refrigerant

Technical Specifications

Model	SF-200
Applicable Temperature	15°C to -18°C
Cooling Capacity (35°C environment)	0°C: 2100 Kcal -18°C: 1210 Kcal
Compressor	Model: SD5H11/5H14 Displacement: 110cc/138cc
Condenser	Type: P.F. Fan: 1 Axial fan (1000m³/h)
Voltage	DC 12V/DC 24V
Evaporator	Type: Inner screw tube and aluminium fin Fan: 1 Axial fan (1000m³/h)
Power Consumption	≤ 33A (DC12V) ≤ 16.5A (DC24V)
Refrigerant	R-134a/R-404a
Defrost Type	Automatically hot air defrost
Structure	Split direct drive unit
Dimensions & Weight	SF-200 Evaporator: 610×790×180mm (16.5kg) SF-200 Condenser: 520×840×315mm (18.2kg) SF-T200 Condenser: 610×790×180mm (21.33kg) SF-T200 Condenser: 920×660×200mm (23.33kg)

Global Quality Assurance

SNOWFALL refrigeration units are manufactured to the highest quality standards in Guangzhou, China. Our products have been successfully exported to multiple global markets including:

North and South America
Eastern and Western Europe
Southeast and Eastern Asia
Africa and Oceania
Middle East markets

All units come with comprehensive OEM support and customization options to meet specific customer requirements.
